Detalhes do produto:
|
| Quantidade do dispositivo elétrico: | 2 | Material do PWB: | FR4, alumínio |
|---|---|---|---|
| Espessura do PWB: | 0.8-3.0mm | Aplicação: | Painel da aba PCBA |
| Precisão do corte: | ±0.05mm | Tamanho máximo do PWB: | 300x350mm |
| Bocado do roteamento: | Diâmetro 0.8-2.5mm | Garantia: | 2 anos |
| a instalação no local: | sim | Nome do produto: | Router do PWB |
| Realçar: | 0.8mm Routing Bit PCB Router Machine,Industrial IPC PCB Router Machine,0.01mm PCB Cutting Machine |
||
Automatic PCB Router Machine For High Speed And Accuracy Cutting
PCB router depanel with high precision controlling system can move quickly for cutting or separate the PCB printed circuit board,increase productivity while maintaining high accuracy.
It is widely used in the Manufacturing Machinery Electronic Products Machinery industry.
Automatic PCB Router Machine Parameters:
| Router Machine | |
| X/Y Cutting Speed | 0 ~100mm/s |
| Repeatability precision | ± 0.01mm |
| X/Y1/Y2/Z control mode | Industrial IPC and PC |
| X/Y1/Y2/Z driven mode | AC Servo Motor |
| Operation and data storage | PC |
| Cutting Precision | ± 0.05mm |
| Spindle Speed | 60000rpm(Germany KKAVO) |
| Power Supply | 220V/110V |
| Air Pressure | 4.5kg/cm 2 |
| Power Rate | 1.8KW |
| Vacuum Cleaner | |
| Mode | Up or Bottom |
| Power Supply | 380V |
| Up Cleaner Dimension | L650*W400*H1350mm |
| Bottom Cleaner Dimension | L665*W635*H1650mm |
Automatic PCB Router Machine Working Area:
| Working Table | Model No. | Description | Working Area | Machine Dimension(mm) | Machine Weight(kgs) |
| Dual | SMTR05 | Standard | 300x350mm | 1382x1056x1500 | 840 |
| Dual | SMTR05 | Larger | 500x500mm | 1682x1356x1500 | 940 |
Automatic PCB Router Machine Two Tables:
Automatic PCB Router Machine Includes:
Vacuum cleaner
Routing spindle
4 aix step motor and driving system
Milling cutter 10pcs
1 year parts warranty
Automatic PCB Router Machine Packaging:
